NPN/PNP All In One Optic Label Sensor S-2700NP

NPN/PNP All In One Optic Label Sensor S-2700NP, plastic housing with NPN and PNP, two outputs in one sensor body, and also normally opened and normally closed can be switched, save you cost to keep many kinds models in your storage.

Detailed description

1. High speed response: 10KHz;
2. Lable Non-transparent tape or mark on transparent tape detectable;
3. Plastic housing, easy setting;
4. NPN/PNP, NO/NC all in one.

Models Guide:

Models	Cable and Ouput
S-2700NP	Pre-wired 2M cable

PS: with "NP" mean NPN and PNP together.

Specifications:

Model	S-2700NP
Detection distance	2mm
Operation voltage	DC 10 ~ 30 v including 10% wave values (P - P)
consumption Current	40mA max
Response time	100μs
Frequency	10kHz
Control Output	1 NPN transistor collector output, normally open; or 1 PNP transistor normally open collector output .
Control Output	Black wire: PNP output White wire: NPN output
Insulation resistant	200MΩ min. (DC500V)
Ambient illumination	Sunlight: 5,000 Lux Max., incandescent lamp: 3,000 Lux Max.
Ambient humidity	Operating : 35~85%RH, storage: 35~85%RH ( No icing or condensation )
Sensitivity adjustment	Potentiometer adjustment, NO or NC switched
Environmental temperature	Operating : -20℃~70℃, storage: -25℃~75℃ ( No icing or condensation )
Material appearance	PC
Wiring method	Pre-wired 2M cable
Weight	Aprrox.65g
